MICROWAVE AND RF CONNECTORS |
 |
|
|
MICROWAVE AND RF CONNECTORS |
|
AVIEL ELECTRONICS innovative design and manufacturing capabilities allow for a quick reaction to your specific needs and short lead time for prototype components, generally without non-recurring engineering or tooling costs.
With interfaces conforming to MIL-C-39012 and MIL-STD-348, AVIEL ELECTRONICS will design and fabricate connectors for various cables, including semi-rigid, foam and tape low-loss dielectric and the more common RG series with various characteristic impedance levels. In addition, we offer a variety of other mounting methods such as flange mount, bulkhead, screw-in, snap-on, blind mate and blind mate-floating designs.
Connector sizes range from sub-miniature to type "L" as well as Nano-Hex, SMA, SMB, SMC, TNC, BNC, N, SC and HN; as well as non-standard configurations required for specific applications.
DIFFICULT TO LOCATE CONNECTORS
AVIEL ELECTRONICS specializes in manufacturing connectors that are of a standard configuration but are not easily obtainable including discontinued series of other connector manufacturers. Aviel Electronics can cross reference to many of the more common connectors manufactured by other connector suppliers. Typical items include blindmates, SMA, SMC, MCX and other miniatures, as well as BNC, TNC, N, C, and NH series. Aviel Electronics will design and manufacture connectors to solve your specific problems.
F.C.C. COMPLIANT ANTENNA CONNECTORS
AVIEL ELECTRONICS will design and fabricate "Unique Coupling Connectors" to bring your antenna into compliance with part 15.203 of the federal regulation for antennas.
Flange mount, crimp and compression cable mounts can be used with uniquely interfaced connector pairs to preclude the possibility of erroneous component mismating. "Coded" pairs can also be fabricated to add further uniqueness within a family of connector components.
Cable Strain Relief |
Hermeticity |
|
PCB Footprint Size |
Plating |
|
Blind Mating |
Blind-Mate Floating Needs |
|
Erroneous Cross Mating |
Assembly Time and Costs |
|
Miniature Cable Mating |
Special Interfaces |
For almost forty years, AVIEL ELECTRONICS has served the microwave transmission industry with high quality products, personalized service and the best possible deliveries. AVIEL ELECTRONICS is approved by many of the leading aerospace, electronics O.E.M. manufactureres and government agencies in the United States and abroad.
CLICK HERE FOR A QUICK BUILD-TO-ORDER WORKSHEET
